HP48X80T-3 High-Quality China Hot Pressing Machine Exporters
Parameters
Model |
HP48x80T-3 |
Maximum pressure |
80T |
Number of working layers |
3 |
Number and specifications of hot press plate |
4-42x2500x1300mm |
Spacing of hot press plate |
120mm |
Oil cylinder |
90x6pcs |
Hydraulic motor power |
4kW |
Heat pump power |
2.2kW |
Heating pipe power |
48kW |
Dimensions |
3500x1700x2400mm |
Net weight |
8000kg |
Introduction
- Pressure plate design with uniform temperature distribution system over the entire surface.
- The pressure plates run parallel and smoothly, resulting in good processing results.
- Rigid structure prevents thermal deformation and provides long service life.
- Equipped with an emergency stop control device to ensure the safety of operators.
