FZB509 Automatic Edge Banding Machine Woodworking Machinery

Short Description:

Say goodbye to tedious and time-consuming edgebanding with our FZB509 auto edge bander. With an array of advanced features, the auto edge bander is a game changer for woodworking professionals and enthusiasts. Whether you are working on cabinets, furniture, or other woodworking projects, this machine is the ultimate tool to improve the quality and efficiency of your edgebanding process. Invest in the power of automation and precision with our auto edge bander. Find out how it can transform your woodworking and take your craft to the next level. Say hello to effortless edgebanding and embrace the art of woodworking with confidence and ease. Order your FZB509 auto edge bander now!


Product Detail

Product Tags

Details

Pre-milling

Gluing 1

Gluing 2

End cutting

Rough trimming

Fine trimming

Round trimming

Scraping

Buffing

- Pre-milling device, using double milling cutters, re-processing the wave pattern marks, non-vertical phenomena when sawing the board, burrs, burrs and edge collapse, etc., to improve the accuracy of the board and achieve better edge banding effect.

- Gluing 1 and Gluing 2 devices, evenly apply glue to the side of the board. At the same time, pressing can make the edge banding and the board bonded together, and the bonding force is stronger.

- End cutting device, through precise linear guide movement, using the mold automatic tracking and high-frequency high-speed motor fast cutting structure to ensure the smoothness of the cut surface.

- Rough trimming device, to ensure the smoothness of the upper and lower parts of the board trimming, used to trim the excess edge banding on the upper and lower parts of the processed board.

- Fine trimming device, fine trimming of the reserved part after rough trimming.

- Round trimming device, rounding the upper and lower corners, can make the end face of the board smoother and more beautiful.

- Scraping device, used to eliminate the ripple marks caused by the cutting process of trimming non-linear motion, making the upper and lower parts of the board smoother and neater.

- Buffing device, use cotton polishing wheel to clean the processed board, and make the edge surface smoother through buffing.

Parameters

Model

FZB509

Total power

22.2kW

Overall size

8800x950x1695mm

Feed speed

16-23m/min

Edge thickness

0.4-3mm

Panel thickness

9-60mm

Panel length

≥100mm

Panel width

≥80mm

Weight

2900kg

Introduction

Take your woodworking projects to new heights and unleash your creativity with automated edgebanding solutions. The FZB509 auto edge bander simplifies and automates the edgebanding process, saving you time and effort while delivering impeccable results. Designed with precision engineering and cutting-edge technology, our auto edge bander delivers superior performance and reliability. From pre-milling to buffing, this machine is equipped with all the essential features to ensure your projects achieve precise, perfect edges.

The pre-milling function of the FZB509 auto edge bander ensures perfectly smooth and even edges on your workpiece, providing a solid foundation for the edge banding process. With the gluing 1 and gluing 2 functions, our machine can accurately and consistently apply adhesive to the edge of the workpiece, ensuring a strong and lasting bond between the edge banding and the substrate. A clean, precise end cut is achieved with the end cutting function, ensuring that the edge banding is neatly trimmed to the required length for a professional finish. The rough trimming function of our machine effectively trims excess edge banding material to prepare the edge for the next stage of the process. The fine trimming function carefully trims the edge banding to achieve a smooth, seamless edge that enhances the overall look of your woodworking project. Use the round trimming function to create beautifully rounded edges that add a touch of elegance and sophistication to your workpiece. The scraping function removes excess adhesive and ensures a clean edge without any blemishes for a perfect edge seal. Finally, the buffing function adds the perfect finishing touch, giving the edge of your workpiece a smooth, shiny, and impressive look.

In addition to advanced features, our FZB509 auto edge bander is user-friendly and intuitive for both experienced professionals and woodworking enthusiasts. Its ergonomic design and easy-to-use controls ensure that you can operate the machine with confidence and ease, allowing you to focus on unleashing your creativity and craftsmanship. In addition, our machines are built to ensure long-term durability and consistent performance. Its solid construction and high-quality components make it a solid investment for your woodworking shop or production facility. Experience the future of edgebanding with the auto edge bander. Say goodbye to manual labor and hello to precision, efficiency and impeccable results. If you are interested in our FZB509 auto edge bander, please consult us to learn more.
